High-Performance Hydraulic Lifts for Efficient Cargo Handling
Safety Device:Explosion-Proof Valve
Lifting Speed:6M/min
Oil Cylinder:Double Cylinder
Application:Warehouse Cargo Transport
Structure Type:Vertical Lifting
Discover our advanced hydraulic lifts designed to improve efficiency and safety in warehouse and factory operations.
Our hydraulic lifts provide a reliable and efficient solution for vertical material handling in warehouses, factories, and logistics centers. With high load capacity and stable performance, they help reduce labor costs and improve operational safety.
Product Description:
Our industrial freight elevators cater to multi-sector logistics needs, featuring a 2m×2m platform and 0.5-20 ton load capacity for seamless material handling. Equipped with an electro-hydraulic drive system, the lift mechanism ensures precision control during vertical transportation up to 6-meter stroke heights.Double-layer safety protocols include instantaneous emergency braking and fail-safe mechanical locks to guarantee operational integrity. Ideal for multi-level facilities, this vertical conveyor reaches 7-story heights, enabling efficient inter-floor material transfer in manufacturing complexes. Invest in long-term reliability with our corrosion-resistant lifts designed for 24/7 industrial operation, minimizing maintenance cycles through premium componentry.The electro-hydraulic power unit delivers variable speed control during ascents/descents, ensuring gentle handling of fragile cargo while maintaining 6m/min max velocity.Backed by a 1-year structural warranty and 24-hour technical support, our lifts provide peace of mind alongside their operational capabilities.
Technical Parameter | ||||||
Specifications, sizes and colors can be customized according to customer requirements | ||||||
Model | Rated load (kg) | Lifting stroke (mm) | Lowering height (mm) | Table size (mm) | Lifting time | Motor power (kw) |
DSL1-3 | 1000 | 3000 | 100 | 2000×1800 | 6m/min | 3 |
DSL1-12 | 1000 | 12000 | 100 | 2500×2000 | 6m/min | 3 |
DSL2-4 | 2000 | 4000 | 150 | 2000×1800 | 6m/min | 4 |
DSL2-10 | 2000 | 10000 | 200 | 3000×3500 | 6m/min | 4 |
DSL3-5 | 3000 | 5000 | 150 | 3000×1800 | 6m/min | 5.5 |
DSL3-8 | 3000 | 8000 | 150 | 2000×1700 | 6m/min | 5.5 |
DSL4-5 | 4000 | 5000 | 250 | 3000×4000 | 6m/min | 7.5 |
DSL4-10 | 4000 | 10000 | 150 | 5000×3000 | 6m/min | 7.5 |
DSL5-6 | 5000 | 6000 | 400 | 5800×3000 | 6m/min | 11 |
DSL10-15 | 10000 | 15000 | 400 | 7000×5000 | 6m/min | 18.5 |
DSL15-9 | 15000 | 9000 | 800 | 8000×4000 | 6m/min | 30 |
DSL15-10 | 15000 | 10000 | 800 | 9000×4500 | 6m/min | 30 |
